Assa Abloy Lockwood 5782ELSS Slimline Electric Mortice Lock Monitored Fail Safe

5782EL Series Short Backseat Electric Mortice Locks

Designed to meet the varying requirements of commercial applications, the lock is the ideal complement to high-security access control systems and a great locking product to use with intercoms, keypads and key switches due to the intuitive operation of a locked or unlocked handle. These locks comply with building regulations for single-action escape doors. The 3782EL is a fully field configurable primary electric mortice lock providing significant benefit over previous models. The unique motor-driven operation, high-security monitoring capabilities and onboard door status LEDs provide a significant advancement in the specification, distribution, installation and servicing of electric mortice locks.

Model: 5782ELSS

Features

• • Variable voltage from 9 – 28VDC
• Simple in field selection of power to lock or power to open
• Full range of monitoring including Request to Exit (REX), Deadlatch, Door position, Key Override Monitoring (KOM) and locked status
• On-board door status LEDs improves installation and reliability
• Unique functions for the reader in / reader out applications which allow external side to fail securely while the internal side fails safe allowing free egress
• Motor-driven providing lower power usage in power to lock applications
• 3 wire control means the power can be supplied independently to the locking control signal making the lock less susceptible to issues associated with the voltage drop across long wiring runs

Downloads

Assa Abloy Lockwood Slimline Electric Mortice Lock Monitored Fail-Safe, 5782ELSS Datasheet
