Assa Abloy Lockwood EMZ4-DN Magnet 12/24 Vdc Double Non- Monitored

EMZ4 Series Magnet 12/24 Vdc Double Non-Monitored

The Lockwood Padde Series Double Series Electromagnetic Locks operate with holding forces from 500kg up to 1160kg. Covering a range of applications these magnets are ideal for applications from access ways through to high use commercial swing doors. With fixing options including wood, aluminium and steel constructions as well as glass door applications, the range caters to most electromagnetic needs.

Model: EMZ4-DN

Features

• Fail-safe: unlocks when power is removed
• Easy installation: suitable for both new and retrofit usage
• High holding force: refer to the technical data overleaf
• Self-alignment: armature plate pivots to accommodate door drop
• Silent operation: no humming or buzzing
• Dual voltage: site selectable 12 or 24 Vdc
• Instantaneous release: smart electronics on the electromagnets eliminate residual magnetism
• 5 Year Tricare Warranty (Padde Series)

Downloads

Assa Abloy Lockwood EMZ4 Series Magnet 12/24 Vdc Double Non- Monitored, EMZ4-DN Datasheet
