Assa Abloy Lockwood EMZ8-DN Magnetic Door Lock, Double Non- Monitored

The EMZ8-DN is a double non monitored magnetic door lock designed for fail safe use, It operates on 12/24VDC and is part of the EMZ8 series.

The Lockwood Padde Series Double Series Electromagnetic Locks operate with holding forces from 500kg up to 1160kg.

Covering a range of applications these magnets are ideal for applications from access ways through to high-use commercial swing doors.

With fixing options including wood, aluminium and steel constructions as well as glass door applications, the range caters to most electromagnetic needs.

Model: EMZ8-DN

Features

• Fail-safe: unlocks when power is removed
• Easy installation: suitable for both new and retrofit usage
• High holding force: refer to the technical data overleaf
• Self-alignment: armature plate pivots to accommodate door drop
• Silent operation: no humming or buzzing
• Dual voltage: site selectable 12 or 24 Vdc
• Instantaneous release: smart electronics on the electromagnets eliminate residual magnetism
• 5 Year Tricare Warranty (Padde Series)

BRAND	ASSA ABLOY
SERIES	LOCKWOOD PADDE SERIES
ELECTRIC/MECHANICAL	ELECTRIC
DEVICE TYPE	DOUBLE MAG LOCK
MONITORED	NON MONITORED
FAIL SAFE/FAIL SECURE	FAIL SAFE (PTL)
MOUNTING	SURFACE MOUNT
FIRE RATING	4 HOUR FIRE RATING
POWER	MULTI VOLTAGE, 12VDC, 24VDC
WARRANTY	60 Months
