Bosch DS9370 Series Panoramic TriTech Detector
Bosch DS9370 Series Panoramic TriTech Detector Stay secure with the peace of mind that comes from knowing you're safely protected from intrusions and false alarms.
Model : DS9370
Each DS9370 Series TriTech PIR/Microwave Doppler radar Motion Detector model is panoramic and uses several patented processing techniques to provide excellent catch performance with freedom from false alarms.
Each model can be mounted on ceilings as high as 6.1 m (20 ft). With three separate PIR sections that are fully adjustable, the DS9370 Series provides coverage integrity at all mounting heights, plus the ability to customize the coverage for specific areas
Features :
- Up to 6.1 m (25 ft) mounting height
- Fully adjustable optics for coverage integrity and customization
- Hinged chassis and base plate for easy installation
- High efficiency LED and light pipe system for easy walk testing
- First Step processing (FSP)
- Microwave adaptive processing
- 360° x 21 m (70 ft) diameter pattern
Specs :
| Design: | Modular chassis and hinged mounting base design provide easy access to field setup switches and wiring. |
| Dimensions: | 8.9 cm x 17.8 cm(3.5 in. X 7 in.) |
| Material: | High impact ABS plastic enclosure |
| Operating Temperature: | -40°C to +49°C (-40°F to +120°F)For UL Certificated installations, 0°C to +49°C (+32°F to +120°F) |
| Radio Frequency Interference (RFI) Immunity: | No alarm or setup on critical frequencies in the range from 26 MHz to 950 MHz at 50 V/m. |
| DS9370-C: | Complies with Environmental Class II (EN50130-5) |
| DS9370 and DS9370-BEL | 10.525 GHz |
| DS9370-C | 10.588 GHz |
| Height Range: | 6.1 m recommended |
| Location: | Mounts directly to ceiling or to standard 10.2 cm (3.5 in.) octagonal electrical box. |
| Alarm: | Form C reed relay rated at 3.0 W, 125 mA at 28 VDC for resistive loads. |
| Tamper: | Cover and ceiling tamper. Normally Closed (with cover in place) tamper switch. Contacts rated at 28 VDC, 125 mA maximum. |
| Current: | 19 mA standby, 39 mA in alarm. |
| Voltage: | 9 VDC to 15 VDC |
