Bosch Panoramic TriTech Detector, Ceiling Mount, DS9360 (Microwave)

Bosch DS9360 is a ceiling mount panoramic motion detector, with motion analyzer II processing microwave adaptive processing and self-test supervision systems, changeable mirrors (two mirrors provided) 360° x 18 m (60 ft) diameter pattern 2.5 m to 6 m (8 ft to 18 ft) mounting height.

Model: DS9360

Features :

• Motion Analyzer II processing
• Microwave adaptive processing
• Self-test supervision systems
• Available on order
• Changeable mirrors (two mirrors provided)
• 360° x 18 m (60 ft) diameter pattern
• 2.5 m to 6 m (8 ft to 18 ft) mounting height

Design:	Modular high impact ABS electronic head and mounting/wiring base design with rugged polyethylene dome provides easy access to field setup switches.
Dimensions:	8.5 cm x 13.3 cm(3.5 in. x 5.25 in.)
Material:	High impact ABS plastic enclosure
Operating Temperature:	-40°C to +49°C (-40°F to +120°F)For UL Certificated installations, 0°C to +49°C (+32°F to +120° F)
Radio Frequency Interference (RFI) Immunity:	No alarm or setup on critical frequencies in the range from 26 MHz to 950 MHz at 50 V/m.
Complies with Environmental Class II (EN50130-5)
Height Range:	2.5 m to 6 m (8 ft to 18 ft) recommended
Location:	Mounts directly to ceiling or to standard 10.2 cm (4 in.) octagonal electrical box.
Alarm:	Form C reed relay rated at 3.0 W, 125 mA at 28 VDC for resistive loads.
Tamper:	Normally-closed (with cover in place) tamper switch. Contacts rated at 28 VDC, 125 mA maximum.
Current:	18 mA standby; 75 mA in alarm
Voltage:	6 VDC to 15 VDC
TriTech® is a registered trademark of Bosch Security Systems, Inc. in the United States.
