Bosch Plug in Communicator Interface, B450-M
Bosch Plug in Communicator Interface (B450-M) It's designed to be easy to install and will increase your connectivity tenfold. With its advanced features, you can expect a reliable and secure connection.
Features
- Full two-way IP communication using Plug-in Cellular Communicators
- Plug and Play installation makes future radio technology changes easy
- Compatible with new and most deployed Bosch control panels
- Supports remote installation of cellular modules for improved signal
Specifications
| Relative humidity | Up to 93% at +32°C (+90°F) non-condensing |
| Operating temperature | 0°C to +50°C (+32°F to +122°F) |
| Dimensions | 79 mm x 128 mm x 38 mm (3.11 in x 5.03 in x 1.50 in) |
| Current (operating) | Standby: With cellular communicator = 60 mA Alarm: With cellular communicator = 180 mA |
| Voltage (operating) | (Bus operation): 12 VDC nominal |
| Data bus wire gauge | 12 AWG to 22 AWG (2.0 mm to .06 mm) |
| USB cable | USB cable (Type A to A male-to-male) – not supplied |
| Data bus wire length | Maximum Distance – wire size 22 AWG (0.6 mm) - 12 m (40 ft) 18 AWG (1.0 mm) - 30 m (100 ft) 16 AWG (1.3 mm) - 48 m (158 ft) 12 AWG (2.0 mm) - 122 m (400 ft) You can extend the wire distances 300 m (1000 ft). Use a separate power supply, such as the B520 Auxiliary Power Supply Module. |
Shop CTC Communications for best deals Bosch Security Products
$109.81
Bosch Plug in Communicator Interface, B450-M—
$109.81
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Bosch Plug in Communicator Interface (B450-M) It's designed to be easy to install and will increase your connectivity tenfold. With its advanced features, you can expect a reliable and secure connection.
Features
- Full two-way IP communication using Plug-in Cellular Communicators
- Plug and Play installation makes future radio technology changes easy
- Compatible with new and most deployed Bosch control panels
- Supports remote installation of cellular modules for improved signal
Specifications
| Relative humidity | Up to 93% at +32°C (+90°F) non-condensing |
| Operating temperature | 0°C to +50°C (+32°F to +122°F) |
| Dimensions | 79 mm x 128 mm x 38 mm (3.11 in x 5.03 in x 1.50 in) |
| Current (operating) | Standby: With cellular communicator = 60 mA Alarm: With cellular communicator = 180 mA |
| Voltage (operating) | (Bus operation): 12 VDC nominal |
| Data bus wire gauge | 12 AWG to 22 AWG (2.0 mm to .06 mm) |
| USB cable | USB cable (Type A to A male-to-male) – not supplied |
| Data bus wire length | Maximum Distance – wire size 22 AWG (0.6 mm) - 12 m (40 ft) 18 AWG (1.0 mm) - 30 m (100 ft) 16 AWG (1.3 mm) - 48 m (158 ft) 12 AWG (2.0 mm) - 122 m (400 ft) You can extend the wire distances 300 m (1000 ft). Use a separate power supply, such as the B520 Auxiliary Power Supply Module. |
