Bosch Pro Series PIR w/Anti-Mask,ISC-PDL1-WA18G

Bosch Pro Series PIR w/Anti-Mask,ISC-PDL1-WA18G

Bosch Professional Series TriTech+ Detectors with Anti‑mask These detectors offer you the ability to detect masked intruders immediately, providing enhanced security for your space.

Model: ISC‑PDL1‑WA18G

Commercial Alarm System Detectors

  • 18 m x 25 m (60 ft x 80 ft) standard coverage, 8 m x 10 m (25 ft x 33 ft) selectable short range coverage
  • EN50131-2-4 Grade 3 compliant
  • Sensor data fusion technology
  • Tri-focus optics technology
  • Range adaptive radar
  • MANTIS anti-mask
  • Active white light suppression
  • Dynamic temperature compensation
  • Remote walk test
  • Alarm memory
  • Draft and insect immunity
Power Requirements
Voltage (Operating): 9 VDC to 15 VDC
Current (Maximum): < 26 mA with alarm, trouble, and LEDs active.
Current (Standby): 18 mA at 12 VDC
Outputs for All Models
Tamper: Normally-closed (NC) contacts (with cover on) rated at 25 VDC, 125 mA maximum.Connect tamper circuit to 24-hour protection circuit.
Trouble: Solid state relay normally-closed (NC) contacts.
Outputs for ISC-PDL1-WA18G and ISC-PDL1-WA18H
Alarm Relay: Solid state relay, normally-closed (NC) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
Outputs for ISC-PDL1-WA18GB
Alarm Relay: Solid state relay, normally-open (NO) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
Enclosure Design
Color: White
Dimensions: 127 mm x 69 mm x 58 mm(5 in. x 2.75 in. x 2.25 in.)
Material: High-impact ABS plastic


Indicators
Alarm Indicator: Blue LED for TriTech+ alarms
Yellow LED for microwave detection
Red LED for PIR detection
Zones
Zones: 86
Relative Humidity: 0 to 95%, non-condensing
Temperature (Operating and Storage): -30°C to +55°C (-22°F to +130°F)For AFNOR certificated installations,-10°C to +55°C (+14°F to +130°F)For UL Certificated installations, 0°C to +49°C (+32°F to +120°F)
Environmental Rating (EN 50130-5): Class II
Protection Rating (EN 60529, EN 50102): IP 41, IK04



Shop CTC Communications for best deals Bosch Security Products

    $59.50

    Original: $169.99

    -65%
    Bosch Pro Series PIR w/Anti-Mask,ISC-PDL1-WA18G—

    $169.99

    $59.50

    Product Information

    Shipping & Returns

    Description

    Bosch Professional Series TriTech+ Detectors with Anti‑mask These detectors offer you the ability to detect masked intruders immediately, providing enhanced security for your space.

    Model: ISC‑PDL1‑WA18G

    Commercial Alarm System Detectors

    • 18 m x 25 m (60 ft x 80 ft) standard coverage, 8 m x 10 m (25 ft x 33 ft) selectable short range coverage
    • EN50131-2-4 Grade 3 compliant
    • Sensor data fusion technology
    • Tri-focus optics technology
    • Range adaptive radar
    • MANTIS anti-mask
    • Active white light suppression
    • Dynamic temperature compensation
    • Remote walk test
    • Alarm memory
    • Draft and insect immunity
    Power Requirements
    Voltage (Operating): 9 VDC to 15 VDC
    Current (Maximum): < 26 mA with alarm, trouble, and LEDs active.
    Current (Standby): 18 mA at 12 VDC
    Outputs for All Models
    Tamper: Normally-closed (NC) contacts (with cover on) rated at 25 VDC, 125 mA maximum.Connect tamper circuit to 24-hour protection circuit.
    Trouble: Solid state relay normally-closed (NC) contacts.
    Outputs for ISC-PDL1-WA18G and ISC-PDL1-WA18H
    Alarm Relay: Solid state relay, normally-closed (NC) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
    Outputs for ISC-PDL1-WA18GB
    Alarm Relay: Solid state relay, normally-open (NO) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
    Enclosure Design
    Color: White
    Dimensions: 127 mm x 69 mm x 58 mm(5 in. x 2.75 in. x 2.25 in.)
    Material: High-impact ABS plastic


    Indicators
    Alarm Indicator: Blue LED for TriTech+ alarms
    Yellow LED for microwave detection
    Red LED for PIR detection
    Zones
    Zones: 86
    Relative Humidity: 0 to 95%, non-condensing
    Temperature (Operating and Storage): -30°C to +55°C (-22°F to +130°F)For AFNOR certificated installations,-10°C to +55°C (+14°F to +130°F)For UL Certificated installations, 0°C to +49°C (+32°F to +120°F)
    Environmental Rating (EN 50130-5): Class II
    Protection Rating (EN 60529, EN 50102): IP 41, IK04



    Shop CTC Communications for best deals Bosch Security Products
