Bosch RFDW-RM Radion Wireless Flush Mount Door/Window Contact Reed

Bosch RFDW-RM RADION Wireless Flush Mount Door/Window Contact Reed

The Bosch RFDW-RM RADION Wireless Flush Mount Door/Window Contact Reed is a concealed wireless reed switch designed to monitor doors and windows on compatible Bosch alarm systems. Installed into the door or window frame, this recessed contact provides discreet perimeter protection without the visible appearance of a standard surface-mounted reed switch.

Ideal for homes, offices, retail stores, apartments, and small business premises, the Bosch RFDW-RM is a practical wireless solution for securing entry doors, internal doors, windows, and other monitored openings where a clean, low-profile finish is preferred.

Key Features of the Bosch RFDW-RM

• Wireless Door/Window Contact – Monitors the opening and closing of doors or windows on compatible Bosch alarm systems.
• Flush Mount Design – Recessed installation provides a concealed, unobtrusive finish.
• Self-Contained Transmitter – Includes an integrated magnetic reed switch contact for wireless alarm signalling.
• RADION Wireless Technology – Designed for use with compatible Bosch RADION receivers and supported Bosch alarm panels.
• Low Battery Supervision – Sends low battery alerts to the alarm system where supported.
• Cover Tamper Protection – Helps alert the system if the device is opened or interfered with.
• Long Battery Life – Operates for up to 5 years using a user-replaceable AAA lithium battery.
• 433.42 MHz Wireless Frequency – Provides reliable wireless communication with supported Bosch receivers.

Ideal Applications

• Front and rear entry doors
• Sliding doors and internal access doors
• Windows and perimeter openings
• Homes, apartments, offices, and shops
• Wireless Bosch alarm upgrades
• Locations where a concealed reed switch is preferred

Compatible Bosch Systems

The Bosch RFDW-RM is designed for compatible Bosch RADION wireless installations and may be used with supported Bosch alarm systems and receivers, including selected:

• Bosch Solution 3000
• Bosch Solution 6000
• Bosch Solution 16i
• Bosch Solution 16 Plus
• Bosch Solution 64
• Bosch Solution 144
• Bosch Solution 880 Ultima
• Compatible Bosch RADION wireless receivers

Product Specifications

Model	RFDW-RM
Device Type	RADION wireless flush mount door/window contact reed
Mounting Type	Concealed recessed/flush mount
Transmitter Dimensions	15.4 mm x 104.7 mm
Magnet Dimensions	22 mm x 28 mm x 15 mm
Power	1 x AAA lithium battery, 1.5 VDC
Battery Life	Up to 5 years
Frequency	433.42 MHz
Relative Humidity	Up to 93% non-condensing
Use	Intended for indoor use

Why Choose the Bosch RFDW-RM?

• Provides discreet door and window protection
• Ideal for clean installations where visible reed switches are not preferred
• Wireless design reduces the need for additional cabling
• Suitable for Bosch wireless alarm upgrades
• Long battery life for low-maintenance operation
• Professionally supplied and supported by CTC Communications

Installation Note

The Bosch RFDW-RM requires a compatible Bosch RADION wireless receiver and supported Bosch alarm panel. Correct alignment between the transmitter and magnet is important for reliable operation, and compatibility should be confirmed before installation.

As this is a recessed flush mount contact, installation may require drilling into the door or window frame. For best results, the Bosch RFDW-RM should be installed and programmed by a qualified security technician.

Professional Bosch Alarm Support

CTC Communications supplies and installs Bosch alarm systems and accessories across Sydney. Our technicians can help confirm compatibility, install your Bosch RFDW-RM wireless flush mount reed switch, and ensure your alarm system is programmed correctly.

Order the Bosch RFDW-RM RADION Wireless Flush Mount Door/Window Contact Reed today or contact CTC Communications for help with Bosch alarm reed switches, wireless receivers, and system upgrades.
