Bosch Solution 6000 PCB Board
Bosch 16 Zone replacement PCB board for Bosch Solution 6000 alarm system, expandable to 144 wired or wireless zones.
Model: CC610P
- 16 on-board zones (expandable to 144 wired or wireless), partitionable to 8 areas with 256 PIN, token, keyfob and fingerprint users
- Integrated access control for up to 16 doors
- Proximity key pads, Weather-proof external metal keypads, Internal
Shop CTC Communications for best deals on Bosch Solution 6000 Alarms Systems.
Specifications
| Voltage Input | 16-18V A.C 50-60Hz 24VA External Power Adaptor or 220-240V A.C. to 18V A.C 50-60Hz 24VA Internal Transformer (Primary Power Source) |
| Continuous Power | 1 Amp MAX (Combined power drawn from Accessory Power (+12V) LAN Power (Module LAN+) and Output Power (C+) terminals must not exceed 1 Amp. |
| Alarm Power | 4 Amp (Total with primary and secondary power sources fitted) |
| Stand-by Battery | 12 VDC, 7.2AH sealed rechargeable battery Panasonic LC-P127R2P or equivalent. (Secondary Power Source). Dispose of used batteries according to instructions. |
| Min Operating Voltage | 10.2 VDC |
| Battery Charger | Pulse by pulse charger. (Note: Charge voltage cannot be measured unless battery is fitted.) |
| Connections | |
| Module Connection (RS485 LAN) | Max. total LAN length using multi strand security cable = 300mMax. total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m.See the product installation manual for complete wiring instructions. |
| Telephone Connections | RJ-12 Socket or 4-way terminal |
| Communications | |
| Communications | CID, SIA, SMS, Email, Voice, Domestic Dialling, GSM-CID, GSM-SMS, Connetix IP, CSV-IP |
| Environmental Considerations | |
| Temperature | 0o to 55oC |
| Relative Humidity | 5 to 85% non-condensing |
| Enclosure Fixing Method | CM720B Small EnclosureUsing appropriate fasteners capable of handling a minimum of 6kgs to fix the cabinet against a sturdy surface using the mounting holes provided.CM730B Large EnclosureUsing appropriate fasteners capable of handling a minimum of 12kgs to fix the cabinet against a sturdy surface using the mounting holes provided. |
| Enclosure Dimensions | MW720B: 385(W), 260(H), 90(D)mmMW730B: 385(W), 520(H), 90(D)mm |
| PWA Dimensions | 235(W), 85(H), 40(D)mm |
| Warranty | 3 years |
$103.07
Original: $294.48
-65%Bosch Solution 6000 PCB Board—
$294.48
$103.07Product Information
