Bosch Surface Mount request to Exit Detector with Sound Alert, DS160
The Bosch Surface Mount request to Exit Detector with Sound Alert, DS160, is ideal for Request-to-exit applications as it is specifically designed for wall or ceiling mounting. Its motion detection capabilities make it a top choice for enhanced security and convenience.
Model: DS160
The DS160 Series consists of the DS160 Detector (light gray) and the DS161 Detector (black) specifically designed for Request-to-exit (REX) applications. With features such as timers, door monitor with sounder alert, and pointable coverage, the DS160 and DS161 have the flexibility to meet the most stringent REX requirements. The exclusive Sequential Logic Input (SLI) provides added security that is not offered in any other REX device.
Alarm System Detectors
- Door monitor with sounder alert
- Sequential Logic Input (SLI)
- Internal vertical pointability
- Wrap-around coverage pattern with precise pattern control
- Up to 64 second adjustable latch time
| Current Draw: | 8 mA nominal standby current, 39 mA at 12 VDC in alarm |
| Voltage: | 12 VAC or VDC; 24 VAC or VDC |
| Alarm Output: | Two Form C relay contacts each rated 1 A at 30 VAC or VDC for resistive loads |
| Indicators: | One activation LED |
| Relay Latch Time: | Adjustable from 0.5 sec to 64 sec. |
| Enclosure Dimensions: | 4.5 cm x 17.1cm x 4.4 cm (1.80 in. x 6.75 in. x 1.75 in.) |
| Enclosure Material: | High impact ABS plastic enclosure |
| Power Loss Default Mode: | Programmable fail-safe or fail-secure modes. |
| Timer Mode: | Programmable reset (accumulative) or non-reset (counting) mode. |
| Mounting Location: | Surface mount on wall or ceiling |
| Operating Temperature: | -29°C to +49°C (-20°F to +120°F) |
| Radio Frequency Interference (RFI) Immunity: | No alarm or setup on critical frequencies in the range from 26 MHz to 1000 MHz at 50 V/m. |
