HiLook 4MP PTZ Camera, PTZ-N2404I-DE3

Smart Features

• Basic Event DetectionMotion Detection, Video Tampering Detection, Exception
• Smart DetectionFace Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
• Smart RecordANR (Automatic Network Replenishment), Dual-VCA
• ROIMain stream, sub-stream, and third stream respectively support two fixed areas.

Network

• Security MeasuresUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
• Network StorageBuilt-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
• APIOpen-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect
• Simultaneous Live ViewUp to 20 channels
• User/HostUp to 32 users,3 levels: Administrator, Operator and User
• ClientiVMS-4200, HikCentral, HiLookVision
• Web BrowserIE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51


• Image Enhancement3D DNR, BLC, HLC, EIS, Regional Exposure, Regional Focus
• Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
• Max. Resolution2560 × 1440
• Main Stream50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
• Third Stream50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Interface

• Audio Input1-ch audio input (line in)
• Audio Output1-ch audio output (line out)
• Network Interface1 RJ45 10 M/100 M Ethernet, PoE

• Camera Module
• Image Sensor1/3" progressive scan CMOS
• Min. IlluminationColor: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
• White BalanceAuto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
• GainAuto/Manual
• Shutter Time50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
• Day & NightIR Cut Filter
• Digital Zoom16×
• Privacy Mask24 programmable privacy masks
• Focus ModeAuto/Semi-automatic/Manual
• WDR120 dB WDR

• General
• MaterialAluminum alloy, PC, PC+ABS
• DimensionsΦ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")
• Approx. 0.53 kg (1.17 lb)
• Protection LevelIP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
• Power

  12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR)

  PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR)

• Working Temperature-20°C to 60°C (-4°F to 140°F)
• Working Humidity≤ 90%

• Supplement Light
• IR Distance20 m
• Smart IRSupport

• PTZ
• Movement Range (Pan)0° to 330°
• Pan SpeedConfigurable, from 0.1°/s to 100°/s, Preset speed: 100°/s
• Movement Range (Tilt)From 0° to 90°
• Tilt SpeedConfigurable, from 0.1°/s to 100°/s, Preset Speed: 100°/s
• Proportional ZoomSupport
• Presets300
• Power-Off MemorySupport

• Compression Standard
• H.264+Support
• H.265+Support
• H.264 TypeBaseline Profile/Main Profile/High Profile
• Video CompressionMain Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG
• H.265 TypeMain Profile
• Video Bitrate32 Kbps to 16384 Kbps
• Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
• Audio Bitrate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)
• SVCSupport

Remote Viewing via HiLookVision App

Stay connected to your property from anywhere. The free HiLookVision app lets you:

• View live and recorded footage remotely

• Receive instant motion alerts

• Playback events and manage recordings

• Control system settings via your smartphone, tablet, or PC
