Sentrol 2202A-L28 Heavy-Duty Roller Shutter Reed Switch, Surface Mount, 3" Gap, NC Metal Contact with Cable

Sentrol's Roller Reed Shutter Heavy Duty SEN1046 provides reliable security solutions with robust construction.

Model: 2202A-L28

The floor mount units are constructed with a low profile heavy cast aluminum housing. The reed switch assembly is fully encased in GE Security’s exclusive polyurethane potting material to prevent damage due to moisture or humidity.

A wide operating gap distance of up to 3 inches makes installation easy and helps prevent false alarms caused by door movement or damaged and loose fitting doors. The 2202 Series is available with a universal style magnet that allows for greater installation flexibility.

Standard Features

• Wide 3-inch operating gap
• Fully sealed switch
• Form C unit available
• Mounting hardwire include

The 2200 Series overhead door magnetic contact is for use in the rigorous environments of commercial and industrial installations

Specifications

BRAND	SENTROL
WIRING	HARDWIRED
DEVICE TYPE	ROLLER DOOR REED SWITCH
COLOUR	SILVER
DETECTION RANGE	DETECTION GAP 76.2MM
ALARM I/O	1 N/C O/P
MATERIAL	METAL
MOUNTING	SURFACE MOUNT
SUITS	SUITS ALL SYSTEMS
