DFM WM88 Heavy‑Duty Roller Shutter Reed Switch, Metal Surface Mount, 50 mm Gap

Highly-Intelligent Hard-Wired Roller Drop Reed Switch with SIL Detector Gap of 50mm; NCX1 Contact Mounted to Metal Surface; 16Hx15Wx106D Contact with 50Hx50Wx106D Magnet; Bracket with 460mm Armored Cable.

The Industrial Roller Shutter Contact used for commercial and industrial applications. Housed in metal alloy for industrial and residential applications this roller shutter contact allows for a 50-60mm gap and has a normally closed output.

The lead is 460mm long with a stainless steel armored cover over 22AWG wire.

Roller shutter door Reed Specs

• Gap : 50-60mm
• Extra wide gap
• 600mm armoured cable (stainless)
• Robust constructed and epoxy sealed – no corrosion
• Universal mounting with L bracket

Size:

• Reed switch : 106 x 36.5 x 10mm
• Magnet : 106 x 15.5 x 16mm
• Bracket : 107 x 50 x 50mm
